NP Steam Erecting Drawings


Product Description

NP Steam Locomotive Erecting Drawings: 104 erecting drawings from the collection of Robert Hundman of Hundman Publishing. The drawings files on this CD are saved as 3- to 8-megabit, JPG files. This format is recognized by virtually all computer software systems, as it is used throughout the Internet to transmit and display photo files. The JPEG files can be resaved into other formats if needed for your application. An Index spreadsheet is included on the CD to make locating specific drawings easy. Copyright NPRHA 2005.
Equipment Classes covered on this CD:
A-1, A-2, A-3, A-5, D-5, G-1, G-2, H-3, L-9, L-10, P, Q, Q-1, Q-2, Q-3, Q-4, Q-5, Q-6, S-4, S-10, T, W, W-2, W-3, W-5, X, Y, Y-2, Z-3, Z-5, Z-6, Z-8, Cab Numerals.
Tenders 1F, 1G, 2G, 8E, 11C. 12C, 13E, 14E, 15E, 21E, 22E, 25E, 27E, 28E, 30E, 31E, 32E, 33E, 34E, 35E, 37E, 39E, 40E, 41E, 42E, 43E, 44E, 47E, 49E, 50E, 52E, 54E, 55E, 59E, Aux.

2.00 Ounces
